Description :
GSM/GPRS/EDGE 850/900/1800/1900MHz/2170MHz
HSUPA/HSDPA/UMTS 2100MHz/900MHz
CDMA 1900 MHz
VSWR ≤1.5
Gain: 2.5 dbi
Max Input power(W): 60
Input Impedance(Ω): 50
Polarization Type: Vertical
Radiation: omnidirectional
Antenna Length（mm）：95±1
Cable Length(mm): 3M default or others
Cable Type RG 174 default
Antenna Connector: SMA
Optional conector: SMA/SSMB/SMB/N/TS9/CRC9/MS147/MCX/MMCX/FME/BNC/TNC/MC-Card..and so on.,please give us notes if the connector is chosen!
Mounting：Screw(Hole/Roof)
Housing: Black
Weight:49g
Storage Temperature: -45'c to +75'c
Operating Temperature: -45'c to+75'c
