Specification
Center Frequency: 1575.42MHz±3 MHz
V.S.W.R<2.0
Band Width:±5 MHz
LNA Gain(Without cable): 28+/-3dB
Noise Figure :1.5dB Typ.
Impendence:50 ohm
Polarization RHCP
DC Voltage 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other
DC Current 5mA /11mA/15mA Max
Cable:RG174 3 meter/9.8 feet
Connector:Fakra C female right angle
Application
Automobile GPS
Bluetooth Receiver
Vehicles /Car Tracking Navigation System
AVL / Fleet Management Systems
External Antenna for Handheld GPS
External Antenna for PDA Navigator
Compatible with navigation unit that has fakra blue connection (following models for reference):
VW: MFD2 RNS2, Golf 5, Golf Plus, Jetta, Passat, Touran, Touareg, T5, T5 Multivan RNS300 310, RNS315, RNS500, RNS510
Audi: RNS-E (16: 9),MMI DVD 2G,3G,BNS low line; Becker: RB3; Blaupunkt Travel Pilot EX; Chrysler: RB3
Skoda: RNS2,MFD2,Amundsen,Columbus; SEAT: RNS2,MFD2,Media System Low,Medium,High;
mercedes: E-Klasse W211 Comand APS,CKL W209 APS 50 NTG 1,NTG 2,NTG 2.5,NTG 3,NTG 4
