Description:
12dbi High-gain antenna Increases the signal strength and performance of 3G Wireless Network.
Compatible with 3G mobile broadband wireless router or card.
Quick, simple installation, no software required.
Rubber base for preventing from abrasion,just unscrew your current antenna, and attach this antenna in its place.
Usable indoor or outdoors Enhance and maintain excellent signal quality.
Specification:
Frequency Range(MHz) 850-960/1710-2170
GSM/GPRS/EDGE 850/900/1800/1900MHz
HSUPA/HSDPA/UMTS 2100MHz/900MHz
CDMA 1900 MHz
VSWR ≤1.5
Gain: 12dbi
Max Input power(W): 60
Input Impedance(Ω): 50
Polarization Type: Vertical
Antenna Length(cm): 15cm
Cable Length(cm): 46cm
Cable Type: RG174 default
Connector Type: SMA or customized, optional conector: CRC9/SSMB/TS9/MCX/MMCX/FME/BNC/TNC/SMB/MC-Card/MS-147 etc. ,please give us notes if the connector is chosen!
Mounting: suctorial
Housing: Black
Weight: 50g
Storage Temperature: -45'c to +75'c
Operating Temperature: -45'c to+75'c
Instructions:
Power off wireless device
Plug connector into antenna port on wireless device
Power on wireless device
For best performance place antenna as close to exterior window as possible
Installation Tips:
Antenna should be mounted vertically to maximize performance
Antenna should not be mounted against metal
